Modular softwall cleanrooms are designed to provide clean environments from ISO Standard 14644 Class 3 to Class 8. Softwall cleanrooms are positive air pressure, single air pass, portable modular structures that can be custom manufactured to your specifications.
Standard units consist of painted steel framing that can be fastened to the ground, aluminum casketed ceiling grid with an interior height of 7’ to 10’. Solid clear vinyl curtains enclose the sides with an access door consisting of vinyl strips that overlap. Clean air is provided through the HEPA filter fan units located in the ceiling (quantity based on size & classification). Lighting is provided by the ceiling grid mounted, sealed cleanroom fixtures.
Air passes vertically down through the cleanroom and exits through a space at the bottom perimeter of the curtain walls.
Softwall cleanrooms may require air conditioning to be ducted from your building’s HVAC system or separate supplementary air conditioning can be provided.
Softwall cleanrooms are easy to upgrade to a higher cleanliness should that become necessary as your process and needs change.
The following are features and options you may want to consider:
All of the components for softwall cleanrooms are prefabricated and completely modular. They can be installed by factory-trained personnel or shipped and installed customer.
 |
 |
 |
 |
 |
 |
 |
 |
 |
